Direct Combustion High Temperature Incineration Equipment

Lvquan Direct Combustion High Temperature Incineration Equipment, produced by a leading Chinese manufacturer and supplier, offers competitive prices and superior quality, making it an ideal choice for efficient and environmentally friendly waste incineration.

Send Inquiry

Product Description

LvQuan Direct Combustion High Temperature Incineration Equipment, originating from China, is a state-of-the-art product manufactured and supplied by a renowned manufacturer in the industry. This incineration equipment offers competitive prices, making it an economically viable option for various waste disposal needs. Its exceptional quality, achieved through rigorous manufacturing processes and strict quality control, ensures reliable performance and long-term durability. The Lvquan Direct Combustion High Temperature Incineration Equipment employs direct combustion technology to efficiently incinerate waste at high temperatures, reducing the volume and toxicity of waste while generating energy. Its user-friendly design and efficient operation make it a convenient choice for facilities seeking sustainable and environmentally friendly waste management solutions.

Direct Combustion High Temperature Incineration Equipment, abbreviated as TO, utilizes the heat generated by the combustion ofauxiliary fuel to increase the temperature ofthe combustible harmful gas to the reaction temperature,thus inducing oxidation and decomposition of the gas.



REACTION MECHANISM


APPLICABLE INDUSTRIES AND RANGE

Application Industries Petrochemical, printing, coating/gtuing, coating drying, wire enameling, pharmaceuticals, and chemicals, etc.
Concentration Range 500~3500mg/m²(2-8%LEL).


FEATURES

Waste heat can be recycled Exhaust gas temperature up to 450~500°C,waste heat can be heated heat transfer oil, hot water, fresh air
High purfication eficiency The higher the puritication eficiency with the increase of furnace temperature, the higher the theoretical value can reach 99%.
Easy to operate Traditional electric control orindustrial controller control can be used to start and stop with one key after the parameters are adjusted to achieve unattended supervision.


PROCESS FLOW


PRODUCT CODE

Company Code for Lv Quan Inc.

Product Type for Direct Combustion

High-Temperature Incineration Equipment

Processing Air Volume (1/10).


EQUIPMENT SPECIFICATIONS

Specification Model 200 400 500 600 800 900 1500
Treatment air volume(m³/h) 2000 4000 5000 6000 8000 9000 15000
Heating power(KW) 400 800 1000 1200 1600 1800 2950

Dimension
Diameter(mm) 1800 2200 2500 2500 2900 3100 3500
Length (mm) 4500 4900 5000 6300 7500 8500 10000
Weight (T) 4.5 7.5 9 10 11 13.2 17.5

Note:Other air volumes not shown in the table are non-standard, and can be designed and manufactured separately if required



SELECTION CRITERIA

1.If the waste gas contains corrosive components such as sulfur and chlorine,it is necessary to specify this when selecting the equipment.Corrosion-resistant materials such as SUS2205 or above must be used for processing,and special treatment is required for such gases at the later stage.

2.The concentration of the mixed waste gas entering the direct combustion high-temperature incineration equipment should be <1/4 of the lower explosive limit (LEL)range.

3.The maximum temperature for the incinerator should not exceed≤900℃.High-temperature substances and high-concentra- tion gases need to be diluted before entering the equipment.

4.The gas entering the Direct Combustion High Temperature Incineration Equipment should not contain dust particles or oil mist that can block or arch up the reheater to prevent clogging.

5.Some Direct Combustion High Temperature Incineration Equipments have requirements for the nitrogen oxide emissions from high-temperature incineration equipment. Direct Combustion High Temperature Incineration Equipment is necessary to specify this to select a low-nitrogen combustion system when purchasing the burner.If the waste gas contains a large amount of nitrogen, even a low-nitrogen combustion system may not meet the emission standards, and additional denitration treatment is required.
